RV Water System, Accumulator Tank System – 12Vdc, 4.0 GPM, 4…

Description

A fully assembled pressure set that simplifies the installation of water pressure systems for both the professional and amateur installer. The set consists of a 3-chamber diaphragm pump, strainer, and pre-pressurized accumulator tank with quick connect electrical connections. Serves 3 or more 1/2" (13mm) outlets.

Details

Reduces pump cycling
Increases pump life
Reduces strain on plumbing
Reduces strain on the battery
Reduces noise of your water system
Allows for better control of hot water
Can run dry
Self-Priming
Can be installed vertically or horizontally

Technical specifications

Ports: 1/2" Barb
Pump Voltage: 12V DC
Pump Flow: 4.0 GPM
Pump Shut-Off Pressure: 45 PSI
Pump Max Amperage: 9.0 A
Accumulator Tank Size: 0.75L (0.2 Gallons)
4.0 GPM / 15.0 LPM - 12Volts Self-Priming Water Pressure Pump with Integrated Accumulator Tank.
【Features】Water accumulator tank system capacity contains 3 chamber diaphragm pump 45 PSI with 4.0 GPM water flow and 0.75L pre-pressurized accumulator tank. Self-Priming up to 9.8 vertical feet, lift up to 125 feet, 9.0 Max amps. The upgraded version of the traditional diaphragm pump and accumulator tank can be applied to most water needs environments.
【Excellent Performance】Product operating volume below 40 decibels with thermal protection ability and can be run dry without damage. Equipped with an automatic pressure switch. When the faucet is turned on, the pressure switch is turned on. Owning a water pressure tank helps to smooth water flow and can effectively solve the water pulsating and frequent start-stop problems of the diaphragm pump.
【Increase Water Flow and Reduce Cycling】The 3-chamber volume design provides high volume water flow to 3.5 GPM. Fixed accumulator tank help to smooth water flow and reduce cycling. Instead using the water pump during low water needs, prolongs the service life of the pump.
